Images Flashcards
ID #1
Hippocampal formation
ID #2
base of the pons
ID #3
crus cerebri
What is circled in black?
the fornix - connects hippocampal formation to the mamillary bodies
What is circled in pink
mamillary bodies
what is circled in blue
anterior nucleus of the thalamus
What is circled in white?
PPRF
what is circled in orange?
the abducens nuc
identify 1
superior colliculus
identify 2
inferior colliculus
identify 3
trochlear nerve (only nerve to exit dorsally)
what is the reticular formation
rostral = awake and conscious
caudal = reflex and motor
identify
locus ceruleus (in the pons , reticular formation)
Identify
lateral geniculate nucleus
(gets fibers from optic tract and then sends sub and retrolenticular fibers to the lingula and cuneus of the occipital lobe respectively
Identify
this is a lesion to the temporal lobe near the occipital lobe; a lesion to the what pathway; impairs perception but not action
Identify
midbrain
- one crus cerebri and some tegmentum
Identify
base of pons
Identify
ICP of medulla
Identify
MCP of the pons
Identify
internal capsule
Identify
crus cerebri of midbrain (“cerebral peduncle”)
Identify
bilateral calcificaiton of amygdala –> loss of emotional reactivity
urbach wiethe disease
identify
hypothalamus
