Basic Structure Identification Flashcards
Idenify the following Regions
Identify the Orange and White Pin
Also Indicate which side is Anterior/Posterior
Orange Pins = Corpus Callosum
Whie Pin = Interventricular Foramen
Identify the Blue and White Pins
Also Indicate Which Side is Ant/Post
Blue Pins = Fornix
White pin = Interventricular Foramen
Identify the Following Pins
Also Indicate which side is Ant/Post
Orange Pin = Corpus Callosum
Yellow Pin = Septum Pellucidum
Blue Pins = Fornix
White Pin = Interventricular Foramen
Identify the Following Pins
Also Indicate what side is Ant/Post
Yellow Pin = Thalamus
Blue Pin= Hypothalamus
Orange pin = Mammilary Body (part of hypothalamus)
White Pin = Intervetricular Foramen
Identify the following pins
Also indicate which side is Ant/Post
White pin = Intervetricular foramen
Yellow Pin= Superior Colliculus
Blue Pin = Inferior Colliculus
Blue/Yellow together = Corpora Quadrigemina
Identify the following Pins
Also indicate which side is ant/post
White pin = Intervetricular Foramen
Yellow Pin = Midbrain
Blue Pin = Pons
Orange Pin = Medulla
Identify the following pins
Also indicate which side is Ant/Post
White Pin = Intervetricular Foramen
Green Pins = Paracentral Lobule
Blue Pins = Supplementary Motor Cortex (Area 6)
Orange Pins = Cingulate Gyrus
Identify the following pins AND the orange and yellow line
Also identify ant/post
Green Pins = Paracentral Lobule
Orange Pins = Cingluate gyrus
Yellow pins/yellow line = Cingluate Sulcus
Orange line = Marginal Branch of Cingluate Sulcus
Identify the following pins and the area outlined in orange
Yellow Pins = Cingulate Sulcus
Orange Pins = Cingulate Gyrus
Green Pins = Parieto-occupital Sulcus
Blue Pins = Calcarine sulcus/ Primary visual cortex (area 17)
Orange Area = Isthmus of Cingulate Gyrus
Identify the following pins
Green Pins = Parieto-occipital Sulcus
Blue Pins = Calcarine Sulcus/Primary Visual Cortex
White/Red Pin = Cuneus
White/Black Pin = Lingual Gyrus
Orange pin = Isthmus of Cingulate Gyrus
Identify the Following Arteries Labed A,B,C,D
A.) Basilar Artery
B.) Anterior Inferior Cerebellar Artery (AICA)
C.) Superior Cerebellar Artery
D.) Internal Carotid Artery
Identify the following Nerves indicated by A,B,C,D,E
A.) Olfactory Tract
B.) Optic Nerve
C.) Occulomotor Nerve
D.) Trigeminal Nerve
E.) Facial & Vestibulocochlear Nerve
Identify the Vascular Supply Labeled A-G
A.) Vertebral Artery
B.) Anterior Inferior Cerebellar Artery
C.) Basilar Artery
D.) Superior Cerebellar Artery
E.) Posterior Cerebral Artery
F.) Internal Carotid Artery
G.) Posterior Communicating Artery
Identify the following Cranial Nerves of the Brain Stem A-G
A.) Hypoglossal Nerve
B.) Vestibulocochlear Nerve
C.) Facial Nerve
D.) Trigeminal Nerve
E.) Abducens Nerve
F.) Glospharyngeal Nerve
G.) Vagus Nerve
